Features and Benefits
■ Line Pressure Driven
■ Double Chambered Design
❏ Wide application range
❏ Requires low actuation pressure
❏ Protected diaphragm
■ Dynamic Sealing
❏ Seals at very low pressure
❏ Prevents seal friction and erosion
■ Engineered Plastic Valve Design
❏ Highly durable, chemical and cavitation resistant
■ Short Valve Travel
❏ Smooth changes of flow direction
❏ Eliminates mixing of supply and waste water
■ User- Friendly
❏ Can be installed in various orientations
❏ Simple in-line inspection and service
Typical Applications
■ Automatic Backwash of Filter Batteries
❑ Gravel Filters
❑ Disc Filters
❑ Screen Filters
■ Single Filter Autonomic Backwash System
■ Angled or Straight Installations
IR-2x2-350-P
Filter Backwash
Hydraulic Valve
2X2 Plastic
The BERMAD Model IR-2x2-350-P is a compact 3-port
valve, in a T configuration. It is double chambered,
hydraulically operated, and diaphragm actuated.
Designed for automatic backwashing of filtration systems,
the BERMAD Model IR-2x2-350-P is available in Angle
flow (A) and Straight flow (S) configurations.
Features and Benefits
■ Line Pressure Driven
■ Double Chambered Design
❏ Wide application range
❏ Requires low actuation pressure
❏ Protected diaphragm
■ Dynamic Sealing
❏ Seals at very low pressure
❏ Prevents seal friction and erosion
■ Engineered Plastic Valve Design
❏ Highly durable, chemical and cavitation resistant
■ Short Valve Travel
❏ Smooth changes of flow direction
❏ Eliminates mixing of supply and waste water
■ User- Friendly
❏ Can be installed in various orientations
❏ Simple in-line inspection and service
